Renault Alpine A110 | R4 | R5 | R7 | R12 | R15 | R16 | R17 high torque starter motor
LMS179
STARTER MOTOR INSTRUCTIONSProduct Description
Designed and manufactured in house using only OE platforms, these lightweight, gear reduction and high torque starter motors are ideal for use in hostile or bespoke environments and are warranted for 12 months and in most cases offer twice the power and half the current draw and weight to an original unit. Unless specifically intended for just one application all our units can be rotated 360° on their own axis giving the unit an infinite number of mounting positions to clear any obstruction
Product Specification
| Type | Weight | Voltage | Polarity | Power |
|---|---|---|---|---|
| Denso OSGR *r | 3.7Kg / 8.15lbs | 12V | Both | 1.4kW |
| Rotation | Pinion Teeth | Pinion Dia | ||
| CW | 11 | 29mm |
Applications
Renault 4 / R4 1.0 & 1.1 '78-'93
Renault 5 / R5 1.0 / 1.1 / 1.3 (inc. auto) & 1.4 Alpine Gordini
Renault 7 / R7 1.0 '75-'82
Renault 12 / R12 1.3 '69-'80
Renault 15 / R15 'various'
Renault 16 / R16 all models '65-'79
Renault 17 / R17 all models '72-'76
Renault Alpine A110 (1300cc Gordini & 1420cc Salv Sacco)
Renault Estafette 1.3 '69-'81
Renault Traffic 1.4 '80-'91
Rene Bonnet Djet (Gordini 1108 engine) '61-'64
ARO 10 1.4 Petrol R810 ( 104R ) '86-'99
Dacia 1210 1.2 Petrol EF5 / EF7 ' Berlina ' ( S ) '83-94
Dacia 1307 1.4 Petrol 840 /847 ( 1307 ) '84-'06
Dacia 1310 1.3 / 1.4 Petrol 810 / 817 / 840 / 847 / 84610 ' Berlina ' ( U / X ) '83-'05
Dacia 1325 1.4 Petrol 10200 ( UU11325 ) '89-'96
Dacia 1410 1.4 Petrol 840 / 847 ' Berlina ' ( U / X ) '85-98
Dacia Nova 1.4 / 1.6 Petrol C2J / XUJ ( 521 / 523 / 524 ) '94-'99
Renault 4 0.8 / 1.0 / 1.1 Petrol 680705 / C1C708 / 689710 / 688712 / C1E714 ' Fourgonette ' ( 112C / R112C / R210B / R2340 / R2370 /R1128 ) '71-'93
Renault 5 1.0 / 1.4 Petrol C6J750 / 840730 / 840726 / 840725 / C2J713 / 689710 ( R2382 / R1222 / R1392 / 122B / R8220 / R1229 / R1399 ) '72-85
Renault 12 1.3 Petrol 81002 / 81002A / 81002B ( R1170 ) '69-'80
Renault Alpine A110
Renault Nova 1.4 / 1.6 Petrol C2J / XUJ ( 521 / 523 / 524 ) '94-'99
Renault R12 Gordini '69-'74
Renault R15 TS '72-'75
Renault 16 All Models '65-79
Renault R17 All Model '72-'76
Renault Traffic T900 1.4 Petrol C1J700 Phase I ( T110 ) '89-'91
Original Pinion is 9 tooth - Ours is 11 tooth with an offset plate
