Ford Essex V4 | V6 high torque starter motor
LMS014
STARTER MOTOR INSTRUCTIONSProduct Description
Designed and manufactured in house using only OE platforms, these lightweight, gear reduction and high torque starter motors are ideal for use in hostile or bespoke environments and are warranted for 12 months and in most cases offer twice the power and half the current draw and weight to an original unit. Unless specifically intended for just one application all our units can be rotated 360° on their own axis giving the unit an infinite number of mounting positions to clear any obstruction
Product Specification
| Type | Weight | Voltage | Polarity | Power |
|---|---|---|---|---|
| Denso OSGR *r | 3.7Kg / 8.15lbs | 12V | Both | 1.4kW |
| Rotation | Pinion Teeth | Pinion Dia | ||
| CW | 9 | 29mm |
Applications
Ford Capri 2.L / 3L Petrol EV20L / EV20HL / TV20L / TV30HYP / TV30HYT Mk I / II / III ( ECJ / GECP ) '69-'81
Ford Consul 3.0 Petrol EV30 MK II ( GCU / GNU / GGC ) '72-'75
Ford Granada 3.0 Petrol EV30 Mk I ( GF / GT / GC / GN ) '72-'77
Ford Essex V4 / Essex V6
Marcos - Ford Essex V6
Reliant Scimitar 3.0 Petrol TV30 (3L Essex) SE5 / SE6 ( TW ) '68-'75
TVR Taimar / 3000M / 3000S (3L Essex)
Suits 121 tooth flywheel
